Quality R360LC-7 Excavator Swing Gearbox Reduction 31NA-10150 For Hyundai factory

R360LC-7 Excavator Swing Gearbox Reduction 31NA-10150 For Hyundai

Name: R360LC-7 Excavator Swing Gearbox Reduction 31NA-10150 For Hyundai
Brand: BELPARTS MACHINERY LIMITED
SKU: R360LC-7
Price: 475.00 USD
Availability: InStock

Place of Origin:Guangdong, China

Brand Name:Belparts

Model Number:R360LC-7

Price:negotiation

Supply Ability:1000 Piece/Pieces per Month

Product Details

Highlight:

R360LC-7 Excavator Swing Gearbox

,

31NA-10150 Excavator Swing Gearbox

,

Hyundai Excavator Swing Gearbox

Product Name: Swing Gearbox

Model: R360LC-7

Weight: 344KG

Brand: Hyundai

Package: 60X60x64

Part Number: 31NA-10150

Product Description

Excavator R360LC-7 swing gearbox reduction 31NA-10150 swing gearbox for hyundai

Product parameter:

Product name	swing gearbox
Weight	344KG
Model:	R360LC-7
Part number:	31NA-10150
Brand:	Hyundai
Package:	60X60x64
Delivery time:	Within 2 days after receiving the payment

R360LC-7 Excavator Swing Gearbox Reduction 31NA-10150 For Hyundai

List of spare parts

#	Part No	Part Name	Qty.
*-2	31NA-10150	SWING REDUCTION GEAR	1
1	XKAQ-00144	CASING	1
2	XKAQ-00145	SHAFT-DRIVE	1
2	XKAQ-00300	SHAFT-DRIVE	1
3	XKAQ-00146	BEARING-ROLLER	1
4	XKAQ-00147	PLATE-COVER	1
5	XKAQ-00148	BOLT-HEX	8
6	XKAQ-00149	SEAL-OIL	1
7	XKAQ-00027	BEARING-ROLLER	1
*	XKAQ-00263	CARRIER ASSY 2	1
*	XKAQ-00264	CARRIER ASSY-NO 2	1
8	XKAQ-00150	CARRIER 2	1
8	XKAQ-00251	CARRIER 2	1
10	XKAQ-00152	GEAR-PLANET 2	4
10	XKAQ-00253	GEAR-PLANET 2	4
11	XKAQ-00153	PIN ASSY 2	4
11	XKAQ-00254	PIN ASSY 2	4
N12	@	FUEL INJECTION PIPE & NOZZLE	4
N12	@	FUEL INJECTION PIPE & NOZZLE	4
N33	@	FUEL INJECTION PIPE & NOZZLE	4
13	XKAQ-00050	PIN-SPRING	4
14	XKAQ-00156	WASHER	4
*	XKAQ-00261	CARRIER ASSY-NO 1	1
*	XKAQ-00262	CARRIER ASSY-NO 1	1
15	XKAQ-00157	CARRIER 1	1
15	XKAQ-00325	CARRIER 1	1
16	XKAQ-00158	GEAR-SUN 1	1
16	XKAQ-00257	GEAR-SUN 1	1
17	XKAQ-00774	GEAR-PLANET 1	4
18	XKAQ-00019	PIN 1	4
19	XKAQ-00030	CAGE-NEEDLE	4
20	XKAQ-00040	PLATE-SIDE 2	4
21	XKAQ-00048	PIN-SPRING	4
22	XKAQ-00160	GEAR-RING	1
22	XKAQ-00258	GEAR-RING	1
23	XKAQ-00072	PIN-KNOCK	4
24	XKAQ-00161	BOLT-SOCKET	16
24	XKAQ-00259	BOLT-SOCKET	16
25	XKAQ-00162	SPACER	1
26	XKAQ-00163	GEAR-PINION	1
27	XKAQ-00164	PLATE-LOCK	1
27	XKAQ-00299	PLATE-LOCK	1
28	XKAQ-00042	BOLT-HEX	2
28	XKAQ-00042	BOLT-HEX	4
29	XKAQ-00041	RING-STOP	1
30	XKAQ-00273	PLUG	1
31	XKAQ-00274	PLUG	2
32	XKAQ-00057	PLATE-SIDE 1	4
34	XKAQ-00166	BAR-GAUGE	1
35	XKAQ-00167	PIPE-GAUGE	1
36	XKAQ-00168	WASHER-LOCK	1
36	XKAQ-00292	WASHER-LOCK	2
37	XKAQ-00169	COVER	1
38	XKAQ-00170	BOLT-HEX SOCKET	4
39	XKAQ-00155	PLUG-SOCKET	1
40	XKAQ-00171	RING-SPACER	1
41	XKAQ-00076	PLATE-THRUST	1
41	XKAQ-00260	RING-THRUST	1
42	XKAQ-00143	AIR BREATHER ASSY	1
43	XKAQ-00151	GEAR-SUN 2	1
43	XKAQ-00252	GEAR-SUN 2	1
N	@	FUEL INJECTION PIPE & NOZZLE	1
