Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan

Place of Origin Made in china
Brand Name Doosan
Certification OEM
Model Number DX225LC DX225LCA DX230LC DX220LC
Minimum Order Quantity 1PCS
Price Negotiated price
Packaging Details Wooden case
Delivery Time 1~3 days
Payment Terms T/T,Alibaba trade assurance,PayPal
Supply Ability 1000PCS
Product Details
Model DX225LC DX225LCA DX230LC DX220LC Part Name Travelling Motors
Weight 310 Kg Part Number K1037757
Texture Steel Brand Doosan
High Light

K1037757 Final Drive

,

DX225LC Final Drive

,

DX230LC Final Drive

Leave a Message
Product Description

Excavator DX225LC DX225LCA DX230LC DX220LC travelling motors K1037757 final drive for doosan






Apply for excavator
Part name travelling motors
Brand Doosan
Model DX225LC DX225LCA DX230LC DX220LC
Part number K1037757
Material Alloy Steel
Weight 310 kg
Texture Steel



Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan 0


Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan 1

Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan 2

Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan 3

Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan 4

Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan 5

Excavator DX225LC DX225LCA DX230LC DX220LC Travelling Motors K1037757 Final Drive For Doosan 6

List of spare parts

# Part No Part Name Comment Qty. Price request
* K9008310 SEAL KIT, TRAVEL MOTOR   1 KIT
413 *NA00628 NUT, LOCK   1
C K9007410 CONTROL PART ASS`Y   1
C-1 K9007408 REAR FLANGE ASS`Y   1
C-2 K9007409 REAR FLANGE KIT 22 kg 1
1 *NA00915 REAR FLANGE HE4D01712A 1
23 K9007399 MAIN SPOOL   1
24 1.181-00059 PLUG, FOR MAIN   2
C-3 K9007414 STOPPER ASS`Y   2
26 1.181-00067 PLUG, CHECK   2
27 1.420-00013 VALVE, CHECK   2
28 1.131-00058 SPRING, FOR MAIN   2
30 1.129-00006 SPRING, CHECK   2
31 K9004995 STOPPER A   1
32 K9007381 STOPPER B   1
33 K9007416 SPOOL   1
34 K9007380 SPRING   1
36 S8000321 O-RING   2
37 S8002731 O-RING   2
41 S5700891 PIN, PARALLEL   1
43 S2221471 BOLT, HEX SOCKET   12
46 S8000181 O-RING 1BP18 2
52 2181-1890D2 PLUG, SP PF1/4 2
54 2181-1116D10 PLUG, PT   5
55 2181-1116D2 PLUG, RECHECK   2
63 2181-1890D4 PLUG, RECHECK PF1/2 2
65 1.424-00041 SPOOL(2 SPEED)   1
66 1.131-00001 SPRING   1
68 S6250182 BALL, STEEL   2
71 1.415-00005 ORIFICE   1
74 S8000111 O-RING 1BP11 2
79 1.471-00001 FILTER   1
91 2181-1116D1 PLUG, RECHECK 97123-01111 2
- K9007405 MOTOR, TRAVEL   1
200 K9007407 CYL BLOCK & PISTON KIT   1 KIT
205 K9007406 PISTON ASS`Y   1 SET
204 K9007397 BLOCK, CYLINDER   1
207 K9004447 PLATE, RETAINER   1
208 K9004448 BALL, THRUST   1
202 K9007415 SHAFT, DRIVE 2 kg 1
203 K9007382 PLATE, SWASH   1
209 K9007398 PLATE, TIMING 1 kg 1
212 K9004453 PISTON, PARKING   1
213 1.131-00049 SPRING   12
214 K9004449 SPRING   1
215 412-00013 PLATE, FRICTION   2
216 352-00014 SEPARATOR PLATE(S/M)   2
232 K9007401 SEAL, OIL   1
235 S8001801 O-RING   1
239 S8002101 O-RING   1
242 1.123-00053 PIN, PARALLEL   4
247 S8061800 RING, BACK UP   1
248 S8062100 RING, BACK UP   1
249 K9007400 BEARING, BALL   1
250 1.109-00026 BEARING, BALL   1
260 1.409-00180 PISTON ASSY(2 SPEED) 1 kg 1
261 1.131-00042 SPRING   1
267 1.540-00006 PIVOT   2
275 S8000081 O-RING   2
400 K9007413 RELIEF VALVE ASS`Y   2
401 *NA00890 PLUNGER HE4D02504B 1
402 1.180-00527 SEAL, PISTON   1
403 *NA00079 BODY HE4D01468C 1
404 S8060161 RING, BACK-UP 5 kg 2
405 S8000161 O-RING 1BP16 3
406 S8010291 O-RING   1
407 *NA00926 RETAINER, SPRING   1
408 *NA01182 SPRING SIS 1
409 *NA00796 PISTON SIS 1
410 S8000221 O-RING   2
411 S8060221 RING, BACK UP   3
412 *NA00865 PLUG, ADJUST   1
