Belparts Excavator Main Pump For Hitachi EX300-5 EX330LC-5 EX350H-5 EX370 Hydraulic Pump 9166355 9169055 9166356 9169054
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model | EX300-5 EX330LC-5 EX350H-5 EX370-5 | Part Number | 9166355 9169055 9166356 9169054 |
|---|---|---|---|
| Warranty | 1 Year | Texture | Steel |
| Part Name | Hydraulic Pump | ||
| High Light | EX330LC-5 Excavator Main Pump,EX370 Excavator Main Pump,9169054 Excavator Main Pump |
||
Product Description
EX300-5 EX330LC-5 EX350H-5 EX370 hydraulic pump Belparts excavator main pump for hitachi 9166355 9169055 9166356 9169054
Appliion:Crawler excavator
Part name:Hydraulic Main Pump
Model:EX300-5 EX330LC-5 EX350H-5 EX370-5
Part number:9166355 9169055 9166356 9169054
Warranty:3-12 months
Payment term:T/T, Trade Assurance, Paypal and etc.
Brand:Hitachi or as require
| Appliion | Crawler excavator |
| Part name | Hydraulic Main Pump |
| Model | EX300-5 EX330LC-5 EX350H-5 EX370-5 |
| Part number | 9166355 9169055 9166356 9169054 |
| Warranty | 3-12 months |
| Payment term | T/T, Trade Assurance, Paypal and etc. |
| Brand | Hitachi or as require |
| # | Part No | Part Name | Qty. | Price request |
| 9166355 | PUMP DEVICE | 1 | ||
| (9169055) | PUMP DEVICE | |||
| 03 | 1019384 | . CASING; GEAR | ||
| 03 | 1026550 | . CASING; GEAR | 1 | |
| 04 | 3035852 | . GEAR; CENTER | ||
| 05 | 3081085 | . SHAFT; CENTER | ||
| 08 | 4395453 | . BRG.; BALL | ||
| 09 | 4395457 | . BRG.; BALL | ||
| 10 | 4191219 | . RING; RETAINING | 1 | |
| 11 | 4179833 | . SEAL; OIL | 1 | |
| 12 | 3033593 | . COVER; T.MISSION | 1 | |
| 13 | 4179834 | . O-RING | 1 | |
| 14 | 991733 | . RING; RETAINING | 1 | |
| 17 | 4181700 | . PUMP; GEAR | 1 | |
| 18 | M341030 | . BOLT; SOCKET | ||
| 20 | 984054 | . WASHER; SPRING | 2 | |
| 22 | 4114402 | . WASHER | 2 | |
| 23 | 4191974 | . ADAPTER | 1 | |
| 23A | 4506418 | .. O-RING | 1 | |
| 28 | 3035853 | . GEAR; DRIVE | 2 | |
| 29 | 991345 | . RING; RETAINING | 2 | |
| 32 | 9166356 | . PUMP; UNIT | 2 | |
| (9169054) | PUMP DEVICE | |||
| 35 | J901645 | . BOLT | ||
| 36 | 4126090 | . WASHER; SEAL | ||
| 37 | A590916 | . WASHER; SPRING | ||
| 40 | 4234782 | . PLUG | 1 | |
| 41 | 94-0649 | . ELBOW | ||
| 50 | 4192946 | . PIPE | 2 | |
| 52 | 4192947 | . PIPE | 1 | |
| 53 | 4179837 | . FITTING; PIPE | ||
| 53 | 4293950 | . ELBOW; S | ||
| 53A | 957366 | .. O-RING | 1 | |
| 54 | 4203485 | . FITTING; PIPE | 1 | |
| 54A | 957366 | .. O-RING | 1 | |
| 55 | 3036249 | . PIPE | 1 | |
| 56 | 3036486 | . PIPE | 1 | |
| 57 | 4118499 | . FITTING; PIPE | 4 | |
| 57A | 957366 | .. O-RING | 1 | |
| 59 | 4179843 | . CLAMP | 2 | |
| 60 | J900828 | . BOLT | 1 | |
| 61 | M500807 | . NUT | 1 | |
| 62 | A590908 | . WASHER; SPRING | 1 | |
| 63 | 4242263 | . GAUGE; LEVEL | 1 | |
| 64 | 4242262 | . PIPE | 1 | |
| 65 | M340816 | . BOLT; SOCKET | 2 | |
| 66 | 9742779 | . PACKING | 1 | |
| 67 | 3081037 | . NAME-PLATE | 1 | |
| 68 | M492564 | . SCREW; DRIVE | 2 | |
| 69 | 4265372 | . SENSOR; REVOL. | 1 | |
| 70 | 4306888 | . O-RING | 1 | |
| 71 | A590106 | . WASHER; PLANE | 1 | |
| 72 | M340616 | . BOLT; SOCKET | 1 | |
| 73 | 4191663 | . COUPLING | 1 | |
| 73A | 4216945 | .. HUB | 1 | |
| 73B | 4183170 | .. SCREW; SET | 2 | |
| 73C | 4101345 | .. PIN; SPRING | 12 | |
| 73D | 4216947 | .. INSERT | 4 | |
| 73E | 4216949 | .. BOLT; SOCKET | 4 | |
| 73F | 4216946 | .. INSERT | 4 | |
| 73G | 4216948 | .. BOLT; SOCKET | 4 | |
| 73H | 4216944 | .. COUPLING | 1 | |
| 76 | 4252767 | . BRACKET | 1 | |
| 77 | M340613 | . BOLT; SOCKET | 1 | |
| 78 | 4169516 | . WASHER; SPRING | 1 | |
| 81 | 9134111 | . PLUG | 1 | |
| 81A | 4509180 | .. O-RING | 1 |
|
Hot Products
Customer Review
FAQ
1.How can I be sure the part will fit my excavator ?
Give us correct model number /machine serial number /any numbers on the parts itself . We mainly sell standard and original motor.
2.What are your After-sales service?
Before shipment, Each individual product will be strictly inspected on our factory. In addition. We have a customer Service team to respond to customers' questions within 12 hours. Being helpful in solving customers' problem is always our goal.
3.How long can an order delivery?
If the order less than 10pcs, we will shipping the goods within 7days, more than 10pcs, we will shipping the goods within 15days. Arrival date depends on shipping company.
