Doosan DX80 K9006619 K1042873 igh-Speed Response Excavator Swing Motor
Place of Origin:Made in China
Brand Name:Belparts
Model Number:DX80
Minimum Order Quantity:1 piece
Price:Negotiable price
Payment Terms:T/T,Paypal and Trade Assurance
Supply Ability:1000pieces
Product Details
Highlight:
Doosan DX80 excavator swing motor
,high-speed response swing motor
,excavator swing motor with warranty
Model:
DX80
Part Number:
K9006619 K1042873
Motor Number:
M2X146B-CHB-10A-33
Model Name:
Excavator Swing Motor Assy
Highlight:
DX80 K9006619 K1042873 Excavator Hydraulic Swing Motor
Part Name:
Excavator Slewing Motor
Brand:
Doosan
Condition:
New/used
Product Description
Doosan DX80 K9006619 K1042873 High-Speed Response Excavator Swing Motor
Doosan DX80 K9006619 K1042873 High-Speed Response Excavator Swing Motor
Product Specifiions
| Attribute | Value |
|---|---|
| Model | DX80 |
| Part Number | K9006619 K1042873 |
| Model Name | Excavator swing motor |
| Part Name | Slewing motor |
| Brand | Volvo |
| Condition | New/Used |
| Payment Methods | T/T, PayPal, Trade Assurance |
List of Spare Parts
| # | Part No | Part Name | Comment | Qty. | Price Request |
|---|---|---|---|---|---|
| 28 | 2180-1217D147 | O-RING | 1 | ||
| 29 | 2180-1217D148 | O-RING | 1 | ||
| 30 | 2180-1217D153 | O-RING | 1 | ||
| 31 | S8000161 | O-RING | 1BP16 | 2 | |
| 32 | S8000111 | O-RING | 1BP11 | 2 | |
| 33 | S2215061 | BOLT, HEX SOCKET HEAD | 4 | ||
| 34 | S2206261 | BOLT, HEX SOCKET HEAD | 3 | ||
| 35 | 2181-1950D1 | PLUG, RECHECK | 2 | ||
| 36 | 2181-1116D4 | PLUG, RECHECK | 97123-04111 | 1 | |
| 37 | S6500250 | RING, RETAINING | 4 | ||
| 38 | K9006221 | VALVE, RELLEF | 2 | ||
| 39 | K9006609 | VALVE, BRAKE | 1 kg | 1 | |
| 40 | K9006610 | GAUGE, OIL LEVEL | 1 | ||
| R1 | *NA00348 | CASING, GEAR | 1 | ||
| R2 | K9006602 | SHAFT, PINION | 8 kg | 1 | |
| R3 | K9006215 | BEARING, TAPER ROLLER | 2 kg | 1 | |
| R4 | K9006606 | BEARING, TAPER ROLLER | 1 | ||
| R5 | K9006607 | SEAL, OIL | 1 | ||
| R6 | K9006597 | COVER, BEARING | 1 | ||
| R7 | K9006187 | COLLAR, HALF | 2 | ||
| R8 | K9006598 | CARRIER NO.2 | 2 kg | 1 | |
| R9 | K9006188 | CARRIER(NO.1) | 1 kg | 1 | |
| R11 | K9006599 | RING, INNER NO.2 | 3 | ||
| R12 | K9006190 | RING(NO.1), INNER | 3 | ||
| R13 | K9006608 | BEARING, NEEDLE | 3 | ||
| R14 | K9006219 | BEARING, NEEDLE | 3 | ||
| R15 | K9006600 | GEAR, PLANET NO.2 | 3 | ||
| R16 | K9006192 | GEAR(NO.1), PLANET | 3 | ||
| R17 | K9006601 | GEAR, SUN NO.2 | 1 kg | 1 | |
| R18 | K9006194 | GEAR(NO.1), SUN | 1 | ||
| R19 | K9006196 | WASHER(NO.1), THRUST | 1 | ||
| R20 | K9006197 | PLATE, THRUST | 1 | ||
| R21 | K9006402 | WASHER, THRUST | 12 | ||
| R22 | K9006403 | SCREW | 3 | ||
| R23 | 2181-1116D3 | PLUG, HEX. SOCKET | PT3/8 | 1 | |
| R24 | 2181-1116D1 | PLUG, RECHECK | 97123-01111 | 2 | |
| R25 | S2215271 | BOLT, HEX SOCKET | 6 | ||
| * | K9006619 | SEAL KIT, SWING MOTOR | 1 | ||
| - | K1042873 | MOTOR, SWING | 42 kg | 1 | |
| 1 | *NA00342 | CASING | 1 | ||
| 2 | K9006595 | CASING, VALVE | 5 kg | 1 | |
| 3 | K9006593 | SHAFT, DRIVE | 1 kg | 1 | |
| 4 | K9006220 | BEARING, ROLLER | 1 kg | 1 | |
| 5 | K9006604 | BEARING, BALL | 1 kg | 1 | |
| 6 | K9006605 | SEAL, OIL | 1 | ||
| 7 | K9006603 | PLATE, FRONT | 1 | ||
| 8 | K9006588 | PLATE, RETAINER | 1 | ||
| 9 | K9006611 | PISTON ASSY | 1 | ||
| 11 | K9006589 | BALL, THRUST | 1 | ||
| 12 | K9005957 | WASHER, PLAIN | 1 | ||
| 13 | K9006590 | ROLLER | 3 | ||
| 14 | 2.114-00862 | WASHER | 2 | ||
| 15 | K9006591 | SPRING | 1 | ||
| 16 | S6510420 | RING, RETAINING | 1 | ||
| 17 | K9006612 | BLOCK, CYLINDER | 1 kg | 1 | |
| 18 | 1.412-00064 | PLATE, FRICTION | 2 | ||
| 19 | 1.412-00073 | PLATE, MATING | 1 | ||
| 20 | K9006594 | PISTON, BRAKE | 1 kg | 1 | |
| 21 | K9006592 | SPRING, BRAKE | 16 | ||
| 22 | K9006596 | PLATE, VALVE | 1 | ||
| 23 | K9006202 | PLUNGER | 2 | ||
| 24 | K9006203 | SPRING, CHECK | 2 | ||
| 25 | K9006180 | PLUG | 2 | ||
| 27 | 2180-1217D142 | O-RING | 1 | ||
| 26 | S5700621 | PIN, PARALLEL | 1 |
