Name: KOBELCO SK200-6E SK200LC-6 SK210LC-6E SK230-6E Hydraulic Pump For Excavator Parts YN10V00023F2 YN10V00020F1 YN10V00029F1 K3V112DTP-9TEL-14T K3V112DTP1A9R-9TEL-V Piston Pump
Brand: GUANGZHOU BELPARTS ENGINEERING MACHINERY LIMITED
SKU: SK200-6E SK200LC-6 SK210LC-6E SK230-6E
Price: 475.00 USD
Availability: InStock

Home > Products > Hydraulic Pump Excavator Parts >

KOBELCO SK200-6E SK200LC-6 SK210LC-6E SK230-6E Hydraulic Pump For Excavator Parts YN10V00023F2 YN10V00020F1 YN10V00029F1 K3V112DTP-9TEL-14T K3V112DTP1A9R-9TEL-V Piston Pump

KOBELCO excavator hydraulic pump

SK200-6E hydraulic pump parts

K3V112DTP excavator piston pump

Place of Origin:

China

Brand Name:

Belparts

Certification:

Model Number:

SK200-6E SK200LC-6 SK210LC-6E SK230-6E

Request A Quote

Product Details

Type:

K3V112DTP-9TEL-14T K3V112DTP1A9R-9TEL-V

Part Name:

Hydraulic Pump

Part Number:

YN10V00023F2 YN10V00020F1 YN10V00020F2 YN10V00020F3 YN10V00023F1 YN10V00023F2 YN10V00029F2 YN10V00029F1 YN10V00014F2 YN10V00029F5

Application:

Excavator

Quality:

Made In China OEM / High Quality

Warranty:

12 Months

Shipment:

Sea / Air / Express DHL FEDEX UPS

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

Negotiation

Packaging Details

Wooden Case Packing

Delivery Time

3-7 Day

Payment Terms

L/C,D/A,D/P,T/T,Alibaba TRADE ASSURANCE,Western Union,PAYPAL

Supply Ability

100 PCS / Months

HYUNDAI R450LC-7 R450LC-7A R500LC-7 R500LC-7A Hydraulic pump for Excavator parts K5V200DT-9C0Z-17T 31NB-10020 31NB-10022 Main Piston pump OEM

Get Best Price

Hydraulic Pump For DOOSAN SOLAR 300LC-7A SOLAR 300LC-V Excavator Parts 401-00226B 401-00225A 401-00424 401-00424A 401-00424B 401-00424C Main Piston Pump

Get Best Price

EC300D EC350D EC300DL Hydraulic Pump For VOLVOO Excavator Spare Parts 14639133 Main Piston Pump K5V160DT-158R-1E06-V

Get Best Price

Kobelco SK210-5 Sumitomo SH210A5 CASE CX210 CX210B Hydraulic Pump K3V112DTP1F9R-9Y14-HV K3V112DTP-1X5R-9X14-V For Excavator Parts KRJ10290 KRJ6199 Piston Pump

Get Best Price

+86 18520556972

belparts01@gmail.com

86-020-32384870

Contact Now

Product Description

KOBELCO SK200-6E SK200LC-6 SK210LC-6E SK230-6E Hydraulic Pump For Excavator Parts

High-quality hydraulic pump components for KOBELCO excavator models, including part numbers YN10V00023F2, YN10V00020F1, YN10V00029F1, K3V112DTP-9TEL-14T, and K3V112DTP1A9R-9TEL-V piston pumps.

Product Specifications

Application	Excavator
Part Name	Hydraulic Pump
Machine Model	SK200-6E, SK200LC-6, SK210LC-6E, SK230-6E
Type	K3V112DTP-9TEL-14T, K3V112DTP1A9R-9TEL-V
Part Numbers	YN10V00023F2, YN10V00020F1, YN10V00020F2, YN10V00020F3, YN10V00023F1, YN10V00023F2, YN10V00029F2, YN10V00029F1, YN10V00014F2, YN10V00029F5
Warranty	12 Months
Delivery Time	3-7 Days
Shipment	Express/Freight/Sea/Train
Quality	Made in China OEM / High Quality
MOQ	1 Piece
Payment Term	T/T, Trade Assurance, PayPal and etc
Category	Construction Machinery Part

Parts List

Pos.	Part No	Qty	Parts Name
*	YN10V00020F2	[1]	PUMP
10.	YN10V00020S010	[1]	OIL SEAL
11.	2437U420S111	[1]	SHAFT
11.	2437U420S111	[1]	SHAFT
13.	YN10V00013S113	[1]	SHAFT
116.	YN10V00020S116	[1]	GEAR
123.	2437U213S123	[2]	BEARING
124.	2437U213S124	[2]	BEARING
127.	2441U723S127	[4]	SPACER
141.	NSS	[2]	NOT SOLD SEPARATELY
151.	NSS	[18]	NOT SOLD SEPARATELY
152.	NSS	[18]	NOT SOLD SEPARATELY
153.	2437U213S153	[2]	PLATE
156.	YN10V00005S156	[2]	BUSHING
157.	2437U213S157	[18]	SPRING
211.	2441U242S211	[2]	PLATE
212.	NSS	[2]	NOT SOLD SEPARATELY
214.	NSS	[2]	NOT SOLD SEPARATELY
214.	NSS	[2]	NOT SOLD SEPARATELY
251.	2437U213S251	[2]	PLATE
261.	2437U420S261	[1]	COVER
271.	2437U213S271	[2]	CASE
312.	YN10V00020S312	[1]	BLOCK
313.	NSS	[1]	NOT SOLD SEPARATELY
314.	NSS	[1]	NOT SOLD SEPARATELY
325.	YN10V00013S325	[1]	COVER
401.	2437U213S401	[8]	SCREW
406.	ZS23C06020	[4]	SCREW, Hex Socket Head, M6 x 20mm
407.	ZS23C06030	[3]	SCREW, Hex Socket Head, M6 x 30mm
466.	2441U667S466	[2]	PLUG
468.	2441U436S469	[4]	PLUG
490.	2441U722S490	[27]	PLUG
531.	NSS	[2]	NOT SOLD SEPARATELY
532.	2437U213S532	[2]	PISTON
534.	2437U213S534	[2]	STOP
535.	2437U213S535	[2]	STOP
546.	YN10V00013S546	[2]	SPACER
548.	NSS	[2]	NOT SOLD SEPARATELY
702.	ZD12G03500	[2]	O-RING, 34.40mm ID x 40.60mm OD x 3.10mm
710.	ZD12G09500	[2]	O-RING, 3.1mm Thk x 94.4mm ID, 90 Duro
717.	ZD12G14500	[4]	O-RING, 144.40mm ID x 150.60mm OD x 3.10mm
724.	ZD12P00800	[18]	O-RING, 1.9mm Thk x 7.8mm ID, 90 Duro
725.	ZD12P01100	[6]	O-RING
728.	ZD12P02400	[4]	O-RING
732.	ZD12P01800	[2]	O-RING
789.	ZD85P01800	[2]	RING
792.	ZD85P03500	[2]	BACK-UP RING
806.	ZN12C16010	[2]	NUT
808.	ZN17C20012	[2]	NUT
824.	ZR16X04000	[2]	RING
885.	2441U723S885	[2]	PIN
886.	ZP26D06014	[4]	PIN
901.	ZS91C01000	[2]	BOLT
953.	2437U188S953	[2]	CAP, M10 x 20mm
954.	2437U213S954	[2]	SCREW
981.	2437U407S981	[1]	LABEL
983.	2437U407S983	[2]	RIVET
K.	YN10V00003S011	[1]	PISTON ASSY
K.	2437U213S13	[1]	REPAIR KIT
K.	2437U213S14	[1]	REPAIR KIT
K.	2437U213S30	[1]	REPAIR KIT
K.	2437U213S530	[1]	REPAIR KIT

Related Products

Hydraulic Parts Hydraulic Pump Final Drive Travel Reduction Swing Motor Swing Reduction Control Valve Gear Parts Slew Bearing Engine Assembly Hydraulic Cylinder ECU

Why Choose Us?

Quality Assurance
Fine Workmanship
Price Advantage
Stable Supply

Process Features

Standard production management
Advanced testing equipment
Heat Treatment Technology
Fitting of cylinder block and valve plate

About Our Factory

Belparts operates a large workshop dedicated to excavator parts production, covering all processes from material cutting, welding, heat treating, assembling, debugging, painting, testing, with thorough quality confirmation before leaving the factory.

Frequently Asked Questions

If I only know the excavator model, but cannot offer parts number, what should I do?

If possible, you can send us pictures of old products, nameplate or the size for reference.

What is the warranty of the parts after I purchased hydraulic axial piston pump & motor spare parts?

The warranty is 6/12 Months based on the item details.

How can I pay the order?

We can receive payment through T/T, Western Union, PayPal (for small amount), Alibaba trade assurance.

When will I get the items after I place order?

Once your payment is confirmed, we will arrange the goods within 24 hours; if not in stock, we will inform you before placing the order.

How can I do if there is something wrong with the items?

First of all, we have confidence in the quality of our products. If you find something wrong, please provide pictures for us to check. After confirmation, please return to us and we will provide the correct item.

What are your main products?

We specialize in excavator spare parts, including travel motor gearbox/assembly/parts, swing gearbox/assembly/motor/parts, hydraulic pump assembly/parts and gear parts. We can also supply other excavator parts as per your requirements.
